1
5
- GRAPHICS | NVIDIA® GeForce RTX™ 5070 (8 GB)
- PROCESSOR | Intel® Core™ 7 processor
- MEMORY | 16 GB DDR5-5600 MT/s (2 x 8 GB)
- STORAGE | 1 TB SSD
- DISPLAY | 40.6 cm (16") diagonal, 2K (1920 x 1200), 60-144 Hz, IPS, micro-edge, anti-glare, 300 nits, 62.5% sRGB
Technical Specifications
x
Spec Sheet |
|
| OMEN 16 inch Gaming Laptop PC 16-am0020ca | Download ProductSheet (PDF) |
Supported Operating Systems |
|
| Operating system | Windows 11 Home |
Processor |
|
| Processor family | Intel® Core™ 7 processor |
| Processor | Intel® Core™ 7 240H (up to 5.2 GHz with Intel® Turbo Boost Technology, 24 MB L3 cache, 10 cores, 16 threads) [6,7] |
| Chipset | Intel® integrated SoC |
| Processor core | 10 |
| Processor cache | 24 MB L3 |
Memory |
|
| Memory | 16 GB DDR5-5600 MT/s (2 x 8 GB) |
| Memory Note | Transfer rates up to 5600 MT/s. |
| Memory layout (slots & size) | 2 x 8 GB |
| Memory and storage | 16 GB memory; 1 TB SSD storage |
Graphic Subsystem |
|
| Graphics (integrated) | Intel® Graphics |
| Graphics (discrete) | NVIDIA® GeForce RTX™ 5070 Laptop GPU (8 GB GDDR7 dedicated) |
| Graphics | Discrete |
| Graphics | Integrated |
Connectivity and Communications |
|
| Ports | 1 USB Type-A 10Gbps signaling rate; 2 USB Type-A 5Gbps signaling rate; 1 AC smart pin; 1 HDMI 2.1; 1 headphone/microphone combo; 1 RJ-45; 1 USB Type-C® 10Gbps signaling rate (USB Power Delivery 3.0, DisplayPort™ 1.4, HP Sleep and Charge) [19,42] |
| Wireless | Realtek Wi-Fi 6 (2x2) and Bluetooth® 5.4 wireless card [11,12,13,46] |
| Network interface | Integrated 10/100/1000 GbE LAN |
| Expansion slots | 2 M.2 (SSD) |
| Wireless Note | Modern Standby (Connected) |
Multimedia and Input Devices |
|
| Audio | DTS:X® Ultra; Dual speakers; HP Audio Boost; HyperX |
| Keyboard | Full-size, backlit, shadow black keyboard with numeric keypad and 26-Key Rollover Anti-Ghosting Key technology |
| Pointing device | HP Imagepad |
| Input devices | IR thermal sensor |
Dimensions |
|
| Dimensions (W x D x H) | 35.75 x 26.9 x 2.37 cm (front); 35.75 x 26.9 x 2.54 cm (rear) |
| Package dimensions (W x D x H) | 6.3 x 56.7 x 30.5 cm |
Appearance |
|
| Product color | Shadow black, black chrome logo |
| Product design | Paint finish |
| Color | Shadow black |
Weights |
|
| Weight | 2.43 kg |
| Package weight | 3.77 kg |
Battery and Power |
|
| Battery recharge time | Supports battery fast charge: approximately 50% in 30 minutes [5] |
| Battery type | 4-cell, 70 Wh Li-ion polymer |
| Power supply type | 230 W AC power adapter |
| Battery type footnote number | [23] |
Software and Applications |
|
| Software included | McAfee Online Protection 30-day trial |
| Software - Productivity & finance | 1 month trial for new Microsoft 365 customers [24] |
Security Management |
|
| Security management | Camera privacy shutter; Trusted Platform Module (Firmware TPM) support |
Display Specifications |
|
| Touchscreen | No |
| Display | 40.6 cm (16") diagonal, 2K (1920 x 1200), 60-144 Hz, IPS, micro-edge, anti-glare, 300 nits, 62.5% sRGB |
| Aspect ratio | 16:10 |
| Display | 40.6 cm (16") diagonal 2K display |
| Display | 16" diagonal 2K display |
| Brightness | 300 nits |
| Screen-to-body ratio (without speakers) | 87.49% [18] |
| Flicker-free | Yes [45] |
| Color gamut | 62.5% sRGB |
Drives and Storage Specifications |
|
| Internal Storage | 1 TB PCIe® Gen4 NVMe™ M.2 SSD |
| Cloud service | 100 GB Dropbox storage for 3 months [1] |
Camera Specifications |
|
| Camera | HP True Vision 1080p FHD camera with temporal noise reduction and integrated dual array digital microphones |
[1] 100 GB of free Dropbox storage for 3 months from date of registration. For complete details and terms of use, including cancellation policies, visit the Dropbox website at https://www.dropbox.com/help/space/hp-promotion. Internet service required and not included.
[2] Internet access required and not included. McAfee is pre-installed on your PC and an account is required for activation. Subscription renewal required after trial period. VPN feature is not available in India, China, Syria or North Korea. McAfee is not compatible with Windows 11 in S mode. You'll need to permanently switch out of S mode. There's no charge to switch out of S mode, but you won't be able to turn it back on.
